In short, high temp valve with the operating temperature higher than 425℃, the main material of which is alloy steel or stainless steel or Cr-Ni heat resistant alloy.

What temperature can stainless steel withstand?

Most austenitic steels, with chromium contents of at least 18%, can be used at temperatures up to 870°C and Grades 309, 310 and 2111HTR (UNS S30815) even higher. Most martensitic and ferritic steels have lower resistance to oxidation and hence lower useful operating temperatures.

What is valve material specification?

A forged valve body is produced by forging and machining solid steel. The key specifications for cast steel valves body materials are ASTM A216 (WCA, WCB, WCC), ASTM A352 LCB/LCC (low-temperature), and ASTM A351 CF8/CF8M. ASTM A105, A350 and A182 cover body materials for small size (or high pressure) forged valves.

What is the maximum temperature for carbon steel?

For a prolonged service life, such as 20 years, plain carbon steels are usually limited to a maximum operating temperature of 750°F (399°C); the ½% molybdenum alloy steels to approximately 850°F (454°C); and the stainless steels to considerably higher temperatures depending upon the type used.

What happens if the valves are exposed to very high temperature?

Valves operate at very high temperatures and are subjected to cyclic loading. The failure of the contact conical surface is mainly caused due to elastic and plastic deformation, the fatigue micro- crack, and spalling [10].

How do you choose valve material?

For large valves the load to operate the valve can be high so that high strength materials are preferred. However, these must have adequate corrosion resistance for the fluid being handled. For coated carbon steel or cast iron bodies the usual choice for stems is a stainless steel.

What is the melting point of 316 stainless steel?

1375 – 1400°C
Stainless steel melting points

Is A105 cast or forged?

A105 valve can be forged by plastic deformation to improve the internal structure, good mechanical properties and even grain size. WCB valves by cast liquid forming that can cause tissue segregation and defects and can be used to cast complex workpieces.

What is the minimum temperature for carbon steel?

Impact-tested carbon steel can be specified with minimum design temperatures down to -50° F. (-46° C.). Types 304 or 316 stainless steel can be specified for design temperatures below -50° F. Project piping standards are generally based on the industry piping standard ASME B31.

At what temperature does carbon steel weaken?

Carbon Steel*: 1425-1540°C (2597-2800°F)

How is the intake valve cooled?

The incoming air-fuel mixture tends to cool the intake valve during operation. The heat of compression will ignite the air-fuel mixture too soon.

What is the difference between 316L and Grade 316?

The material has superior welding and forming qualities. Grade 316 will require post-weld annealing to promote maximum corrosion resistance, though this is not necessary if Type 316L is used.

What is the difference between 316L and welded end valves?

Welded end valves can be in 316 but 316L is often preferred due to the lower carbon content which avoids inter granular corrosion in the as-welded state thereby providing superior corrosion resistance compared to 316. However 316 can be post-weld annealed to promote maximum corrosion resistance.

What are the standards for valve & trim components?

The following standards may be utilised for valve & trim components in valve construction:- Corrosive or either extremely low or high temperature non-corrosive services between -450ºF (-268ºC) and +1200ºF (+649ºC). Above +800ºF (+425ºC) specify carbon content of 0.04% or greater.
