Centrifugal Pump Curves – 4 Types of Performance Curves

• Head Vs. Flow Curve (H-Q Curve)
• Efficiency Curve.
• Power / Energy Curve.
• NPSHR curve.
• Pump Family Curve.

How many characteristics curves are there in centrifugal pumps?

Curves relating total head, efficiency, power, and net positive suction head required (NPSHR) to discharge or pump capacity (Q) are utilized to describe the operating properties (characteristics) of a pump. This set of four curves is known as the pump characteristic curves or pump performance curves.

What is a pump operating curve?

What is a pump curve? In short, a pump curve is a graphical representation of a pump’s performance based on testing conducted by the manufacturer. Each pump will has its own pump performance curve and it varies from pump to pump. This is based on the pump horsepower and the size and shape of the impeller.

How do you select a curve from a pump?

Look at the left side of the curve and you will see a label HEAD – FT and numbers starting with 0 and increasing as you move up the chart. This is the pressure that the pump is capable of producing, measured in feet of head (not PSI!) The bottom of the curve is labeled US GPM. This is the flow that the pump produces.

What is ETA in pump curve?

The upper efficiency curve (Eta2) is the pump efficiency curve (eta pump). The lower efficiency curve (Eta1) is the total efficiency curve (eta pump + motor), taking all electrical, mechanical, and hydraulic losses into consideration.

What is centrifugal pump curve?

Centrifugal Pump Curve. Also called a pump selection curve, pump efficiency curve, or pump performance curve, a pump curve chart gives you the information you need to determine a pump’s ability to produce flow under the conditions that affect pump performance.

What are the characteristics curves of centrifugal pump?

The characteristic curves of centrifugal pumps plot the course of the following parameters against flow rate (Q): head (H) (see H/Q curve), power input (P), pump efficiency (η) and NPSHr, i.e. the NPSH required by the pump.

What is the difference between pump curve and system curve?

In general, a pump is used to overcome frictional head loss in piping systems as well as system elevation changes between system boundaries (i.e., static head). The system curve helps quantify the resistance in a system due to friction and elevation change over the range of flows.

How are pump curves generated?

How to Generate Pump Curves. Pump curves can be generated by reading measurements of pressure, NPSH, power, efficiency and others, while the pump is operating at different flow conditions. These results are then plotted against the flow rate to generate the pump characteristic curves.
