For Classes 2 – 9 there are 5 stowage categories (A to E) and the stowage category indicating the applicable requirements for each UN Number appear in column 16a of the DGL and are defined in Chapter 7.1, Paragraph 7.1.

What is stowage category?

Stowage category A Cargo ships or passenger ships carrying a number of Passengers limited to not more than 25 or to 1 passenger per 3 m of overall length, whichever is the greater number. ON DECK OR UNDER DECK. Other passenger ships in which the limiting number of passengers transported is exceeded.

Which IMDG Code deals with stowage?

Introduction. The 2012 Edition (incorporating Amendment 36–12) of the IMDG Code introduced a Part 7 that has been completely reorganised according to job function. Chapters 7.1 and 7.2 contain general stowage and segregation rules.

What is stowage in maritime?

From Wikipedia, the free encyclopedia. In nautical terminology, stowage is the amount of room available for stowing materials aboard a ship, tank or an airplane. In container shipping, stowage planning refers to the arrangement of containers on board a container vessel.

What is the stowage category for UN 0453?

03
Stowage category “03” means the material may be stowed “on deck” in closed cargo transport units or “under deck” on a cargo vessel (up to 12 passengers) but the material is prohibited on a passenger vessel.

What is stowage and segregation?

Segregation is the process of separating two or more substances or articles which are considered mutually incompatible when their packing or stowage together may result in undue hazards in case of leakage or spillage, or any other accident.

What is the stowage category for propylene oxide?

E
Stowage category “E” means the material may be stowed “on deck” or “under deck” on a cargo vessel or on a passenger vessel carrying a number of passengers limited to not more than the larger of 25 passengers, or one passenger per each 3 m of overall vessel length, but is prohibited from carriage on a passenger vessel …

What are the factors to consider in devising a stowage plan?

Other factors included at stowing are:

• Vessel stability. The weight of the cargo should be evenly distributed in the ship.
• Stack weights violation.
• Weight inversion.
• Unused slots under deck should be avoided and the planning should be done from bottom to top.
• Decrease lashing force.

How do I fill out a DD 2890?

How to fill out DD Form 2890?

1. Indicate the address and phone number of dangerous materials’ place of certification;
2. The 2nd box is for ocean shipments.
3. Indicate the total number of pages;
4. Put the TCN there;
5. Box 5 must be left blank, while box 6 is for Activity Address Code;
6. Name the vessel carrier;

What operation does a stowage plan is primarily intended for?

So, what is stowage planning..?? In simple terms, it is the act of allocating space on board the ship for containers that have to be loaded from a certain port(s) to be discharged at certain port(s) without those containers having to be rehandled at any of the way ports along the route..

What is a stowage Category A?

Stowage category A: Cargo ships or passenger ships carrying a number of Passengers limited to not more than 25 or to 1 passenger per 3 m of overall length, whichever is the greater number: ON DECK OR UNDER DECK: Other passenger ships in which the limiting number of passengers transported is exceeded: ON DECK OR UNDER DECK: Stowage category B

What is a standard stowage plan for container ships?

Stowage plan for container ships or bay plan is the plan and method by which different types of container vessels are loaded with containers of specific standard sizes.

What is the stowage requirement for dangerous goods?

For other than class 1 (Explosives) each dangerous goods listed in IMDG Code 36th Amendment, Dangerous Goods List column 16 specifies stowage requirement. This is indicated by Category A, B, C, D or E. On Deck only stowage is always prescribed for cases where: constant supervision is required; or

When is stowage on deck only prescribed?

On Deck only stowage is always prescribed for cases where: constant supervision is required; or accessibility is particularly required; or there is a substantial risk of formation of explosive gas mixtures, development of highly toxic vapours, or unobserved corrosion of the ship
