Normal rule of thumb for vortex flowmeter sizing is at least one line size smaller than the pipe size for most applications. Looking at your requirements, a 1.5 in. vortex would actually give the best results because it has an approximately 0.95 to 34 m³/hr range.

What is a full bore flow meter?

The flow meter’s PVC body with titanium electrodes is designed for high accuracy flow measurement in short pipe runs. A modified sensor design has shorter inlet and outlet pipe-length requirements and certified factory calibration.

What is a variable area flow meter?

The variable area flow meter is an industrial flow meter used to measure the flowrate of liquids and gases. The variable area meter consists of a tube and float. The float response to flowrate changes is linear, and a 10-to-1 flow range or turndown is standard.

How is peak flow meter used?

A peak flow meter is a portable, easy-to-use device that measures how well your lungs are able to expel air. By blowing a quick blast of air through a mouthpiece on one end, the peak flow meter can measure the force of air in liters per minute and give you a reading on a built-in numbered scale.

How does a variable area flow meter work?

The Variable Area Flowmeter is an instrument for measuring the flow of liquids and gases in pipelines. As the flow increases this float moves to a higher position until its resistance to the fluid flow is balanced by the float’s buoyed weight in the fluid, a value which is constant and independent of the flowrate.

Is example of variable area flow meter?

Rotameters. The simplest example of a variable-area flowmeter is the rotameter, which uses a solid object (called a plummet or float) as a flow indicator, suspended in the midst of a tapered tube: As fluid flows upward through the tube, a pressure differential develops across the plummet.

Which flow meter is the most accurate?

Coriolis mass flow meters produce the most accurate for most liquids but are expensive. They have the advantage of not needing any knowledge about the fluid being carried. Thermal mass flow meters are a less accurate but still direct measurement method. They do require knowledge of the fluid’s specific heat capacity.

What is the limitation of the magnetic flow meter?

It can only measure the liquid flow of conductive medium, and can not measure the flow of non-conductive medium, such as gas and water for better heat treatment. In addition, the lining needs to be considered under high temperature conditions.

How do I make an orifice flow meter?

Steps required to design an orifice plate or orifice plate flow meter:

1. Identify the physical attributes of the piping system.
2. Identify and accumulate data on process flow conditions.
3. Identify and accumulate information on other requirements of the flow meter.

What is digital flow meter?

Digital flow meters are high-tech devices with a customizable, touch screen interface. They’re used for gauging and displaying qualities like mass flow rate, volumetric flow rate, gas temperature, atmospheric pressure, and gas pressure.

Why choose Yokogawa magnetic flowmeters?

Yokogawa’s experience with magnetic flowmeters spans decades. Our magnetic flow meters provide flexible configurations for industrial use in most areas. Yokogawa has been synonymous with Vortex flow meters since pioneering the industrial vortex flow meter nearly four decades ago.

Why use Yokogawa for slurry measurement?

Yokogawa is capable of measuring tough slurries, like an AC meter, and having at the same time the zero stability and accuracy of a pulsed DC meter. Low frequency excitation ensures zero stability, while high frequency excitation achieves slurry noise reduction and fast 0.1 second response times necessary for batching applications.

What are the different types of flow meters?

Yokogawa’s range of flow meter instruments include vortex, magnetic, variable area, Coriolis, and differential pressure flow meters. The Coriolis flow meter has many features such as direct measurement of mass flow and measurement of fluid density, which other flow meters do not support.

Why choose Yokogawa dual frequency excitation?

Unique to Yokogawa, dual frequency excitation provides the best of AC and pulsed DC excitation. Yokogawa is capable of measuring tough slurries, like an AC meter, and having at the same time the zero stability and accuracy of a pulsed DC meter.
