After the dependent source has been placed, left click on it to select it. Right-click on it to pop up a menu as shown in figure 3. Edit the property GAIN to set the gain (or constant) for the dependent source. Click the Apply button to set the gain and close this window.

What is G in PSpice?

G Device – Laplace Form. GPOLY. Voltage-Controlled Current Source.

What is a current controlled voltage source?

A voltage source that depends on a current input is referred too as a Current Controlled Voltage Source or CCVS. Ideal dependent sources are commonly used in the analysing the input/output characteristics or the gain of circuit elements such as operational amplifiers, transistors and integrated circuits.

What is probe in PSpice?

The PROBE statement included in the PSPICE Netlist generates a file, PROBE. DAT, for viewing the analysis on the computer monitor. If the PROBE program is executed, an output can be obtained as shown in the figure.

Where is the resistor in PSpice?

You can find the resistor by selecting “Place Part” from the menu or select the icon on the right hand side. In the “Part” field you can search for parts by the name. In your “libraries” submenu make sure that the libraries are highlighted otherwise you will have trouble searching for the part.

How is current controlled in a circuit?

The charge passing through the circuit always passes through an appliance (which acts as a resistor) or through another resistor, which limits the amount of current that can flow through a circuit. The appropriate voltage and resistance in a circuit keeps the current in control and keeps the circuit safe.

Which side of PSpice is the current source?

PSPICE Schematic with Current Controlled Voltage Source Note that the right side of the device goes where the voltage source appears in the circuit. The left side is connected so that the controlling current (in this case I. 0. ) runs through the left side of the dependent source symbol.

How do I create a project in PSpice?

Pspice Tutorial. Create a new project and select “Analog or Mixed A/D”. Choose an appropriate project name and a path. A new window pop up with the Pspice project type, select “Create a blank project” and click ok.

What types of models are included in PSpice® model library?

PSpice® model library includes parameterized models such as BJTs, JFETs, MOSFETs, IGBTs, SCRs, discretes, operational amplifiers, optocouplers, regulators, and PWM controllers from various IC vendors. Cadence® PSpice technology offers more than 33,000 models covering various types of devices that are included in the PSpice software.

What does PSpice stand for?

not present Dependent Source Abbreviation PSPICE Name Voltage Controlled Voltage Source VCVS E Current Controlled Current Source CCCS F Voltage Controlled Current Source VCCS G Current Controlled Voltage Source CCVS H
