Solution

1. Telnet to switch.
2. Set your telnet client to capture text to a file (procedure varies based on the client).
3. Execute the following commands: # term len 0. # show tech-support details.
4. Stop capture and verify that the data shows properly in the capture file; use any text editor, such as wordpad.

How do I redirect show tech-support?

To better manage this output, you can redirect the output to a file (for example, show tech-support > filename ) in the local writable storage file system or the remote file system. You can use one of the following redirection methods: > filename —Redirects the output to a file.

What is show tech command?

show tech-support command. It’s executed in the enable mode (Privileged. EXEC Mode). The command displays diagnosis information for technical support by. running relevant show commands on the hardware.

What is show interface command in Cisco?

The show interfaces command displays statistics for the network interfaces. The resulting display on the Cisco 7200 series routers shows the interface processors in slot order. If you add interface processors after booting the system, they will appear at the end of the list, in the order in which they were inserted.

How do I transfer my show tech to TFTP?

Method 1:

1. Launch a TFTP server utility, and ensure that it is configured to send and receive files.
2. Ensure that the switch and PC are provisioned with IP ranges within the same subnet;
3. Within the CLI of the HP ProCurve Switch, type the command: copy command-output “show tech all” tftp ;

How do you stop a command in Cisco?

Every introductory Cisco course tells you that you can stop any IOS command (for example, ping or traceroute) with the Ctrl/^ (also written as ^^ or Ctrl-Shift-6) escape character.

How do I show all configuration on a Cisco router?

On Cisco Router/Switches:

1. Type “terminal length 0” in privileged mode to set your terminal to display without any breaks.
2. Type “show run” or “show start” to show the applicable config.
3. To display the config without lengthy certificate data, use “show run brief “.

How do I stop a Cisco router from output?

Press Ctrl+C, q, or Q to interrupt the output and return to the command prompt.

What does Ctrl Z do in Cisco?

Ctrl-Z: When in a config mode, ends the config mode and returns you to privileged EXEC mode. When in user or privileged EXEC mode, logs you out of the router. Ctrl-Shift-6: All-purpose break sequence.

Do show running-config command?

The show running-config command shows the router, switch, or firewall’s current configuration. The running-configuration is the config that is in the router’s memory. You change this config when you make changes to the router. This command can be abbreviated sh run.

What is the command to monitor you running configuration?

Show running-config: To display the configuration information currently running on the terminal, use the show running-config EXEC command. This command replaces the write terminal command.

How do I redirect the output of the show Tech-Support Command?

This command was introduced. The output from the show tech-support command is very long. To better manage this output, you can redirect the output to a file (for example, show tech-support > filename ) in the local writable storage file system or the remote file system. You can use one of the following redirection methods:

How do I redirect the output to a file?

To better manage this output, you can redirect the output to a file (for example, show tech-support > filename ) in the local writable storage file system or the remote file system. You can use one of the following redirection methods: > filename —Redirects the output to a file.

What are the usage guidelines for the show Tech Support Command?

Usage Guidelines. The output from the show tech-support command is very long. To better manage this output, you can redirect the output to a file (for example, show tech-support > filename ) in the local writable storage file system or the remote file system.

How do I display information for Cisco technical support?

To display information for Cisco technical support, use the show tech-support command.
