The R&S®RTO digital oscilloscope is capable of analyzing RF pulses with frequencies up to 6 GHz. To analyze the envelope of the RF pulse, the signal has to be demodulated.

What is a bandwidth oscilloscope?

Oscilloscope bandwidth is defined as the frequency at which the amplitude of the observed signal drops by -3 dB (or drops to 70.7% of its actual value) as we increase the test signal’s frequency as plotted on the amplitude-frequency characteristic curve (Figure 1).

What frequency oscilloscope do I need?

Use a sample rate of at least 5x your circuit’s highest frequency component. Oscilloscopes come with a wide variety of sample rates, from 1 to 200 GS/s, to meet the needs of your application. The faster you sample, the less information you’ll lose and the better the scope will represent the signal under test.

How much does a good oscilloscope cost?

An o-scope that has a narrow bandwidth of 200 MHz can go for a few hundred dollars; however, a top of the line oscilloscope with a measurement bandwidth of 1 GHz ca go for almost $30,000!

What bandwidth oscilloscope do I need?

As a rule of thumb, your scope’s bandwidth should be at least five times higher than the fastest digital clock rate in your system under test. If your scope meets this criterion, it will capture up to the fifth harmonic with minimum signal attenuation.

What makes a good oscilloscope?

Select an oscilloscope that has sufficient bandwidth to accurately capture the highest frequency of your signals. Remember ‘the five times rule’- select an oscilloscope which, along with the probe, offers at least 5 times the maximum signal bandwidth for better measurements with fewer errors.

How does the scope measure the RF voltage?

The scope monitors the RF voltage across the 1k Ω resistor. The setup measures one-tenth of the RF voltage as applied to the antenna. When using a 50-Ω cable feeding a matched 50-Ω antenna, the voltage will never be higher than 21 Vrms (30 Vpk), safe for any scope.

What is the best phosphor for band scope?

The phosphor is low persistence, optimum for monitor scope mode; for a band scope, a longer persistence phosphor would have been better. None of the other scopes (Heathkit, Yaesu) even attempt to offer band scope as a feature, in the same package.

Where can I get a band scope for my ft-950?

Check it out at: A completely self contained monitor scope, in two different display sizes and feature sets: He also makes a panadapter. There are alternatives such as an SDR dongle. My FT-950 had a very expensive DMU that provided a band scope as an option.

What are the applications of RF in electronics?

An important application for RF is in wireless communication. Long and short pulses of electromagnetic radiation can be used to convey information using Morse Code, and audio and video information can carry over wire or through a vacuum by modulating the amplitude, frequency or phase of an RF signal, which then becomes known as a carrier wave.
